1948-1950 Ford Truck Aluminum Dash Insert w/ Auto Meter American Muscle Gauges

Name: 1948-1950 Ford Truck Aluminum Dash Insert w/ Auto Meter American Muscle Gauges
SKU: 21009-AM
Availability: InStock

Price range: $879.95 through $890.95

Includes aluminum gauge panel, Auto Meter American Muscle gauges, & LED lights (turn signal & high beam indicators).

Gauges include:

3 3/8” 160 MPH electric speedometer
2 1/16” 100 psi electric oil pressure
2 1/16” 100-250 degree electric water temperature
2 1/16” 8-18 VDC voltmeter
2 1/16” 240-33 ohm fuel level.
Sending units are included for oil pressure, water temperature, fuel level, and speedometer (GM style)

Gauge Panel Finish

Clear

Description

$Gauge Features

Modern white LED through-the-dial lighting provides clear visibility during nighttime use
Kit includes fuel level sender (240E/33F), oil pressure sender, water temperature sender, 2-wire hall-effect speed sender that is compatible with GM/Chrysler applications (7/8″ – 18THD), sending unit adapters (1/4″, 3/8”, and 1/2″ NPT adapters), mounting hardware, and detailed instructions for installation.
AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
Speedometer has a simple push button, 2 mile drive calibration. No dip switches and can be reprogramed at any time to accommodate changes in gear ratio or wheel and tire combination.
Speedometer is compatible with most two wire sine wave and three wire hall effect vehicle speed sensors.
Speedometer features lit LCD odometer – capable of registering one-million miles with two resettable trip odometers
