1953-1954 Chevy Car Billet Aluminum Gauge Panel With Auto Meter Chevy Vintage Gauges
Price range: $676.50 through $687.50
Includes aluminum dash insert, Auto Meter Chevy Vintage gauges & turn signal/high beam indicators.
Gauges include:
- 3 1/8″ 120 MPH electronic speedometer
- 2 1/16″ 100 PSI electric oil pressure
- 2 1/16” 100-250 F water temperature
- 2 1/16” 8-18 VDC voltmeter
- 2 1/16” 240-33 ohm fuel level.
- Sending units are included for the speedometer, oil pressure, water temperature, & fuel gauges.
Mounts into stock bezel (not included).
Installation Instructions
Description
Gauge Features- Traditional incandescent lighting illuminates around the perimeter of the dial
- Kit includes fuel level sender (240E/33F), oil pressure sender, water temperature sender, 2-wire hall-effect speed sender that is compatible with GM/Chrysler applications (7/8″ – 18THD), sending unit adapters (1/4″, 3/8”, and 1/2″ NPT adapters), bulb and socket assemblies, red and green bulb covers, mounting hardware, and detailed instructions for installation.
- AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
- 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
- Speedometer has a simple push button, 2 mile drive calibration. No dip switches and can be reprogramed at any time to accommodate changes in gear ratio or wheel and tire combination.
- Speedometer is compatible with most two wire sine wave and three wire hall effect vehicle speed sensors.
- Speedometer features lit LCD odometer – capable of registering one-million miles with two resettable trip odometers
- Fuel Sender 3262 – Oil Sender 2242 – Water Sender 2258 – 5293 VSS Sensor
- Brackets Included
Additional information
| Weight | 7.25 lbs |
|---|---|
| Dimensions | 17.75 × 9 × 5 in |
| Gauge Panel Finish | Brushed Finish, Polished Finish |
