1957 Ford Fairlane Aluminum 5 Gauge Panel w/ Auto Meter Prestige Series

Name: 1957 Ford Fairlane Aluminum 5 Gauge Panel w/ Auto Meter Prestige Series
SKU: 44602-PS
Availability: InStock

Price range: $967.95 through $1,121.95

Includes aluminum dash insert, Auto Meter Prestige series gauges & turn signal/high beam indicators.

Gauge series choices:

Gauges include:

3 3/8” speedometer (choose 120 MPH electric wheel or LCD odometer) (Black Diamond has an additional option of 140 MPH GPS)
2 1/16” 100 PSI electric oil pressure
2 1/16” 100-250 F electric water temperature
2 1/16” 8-18 VDC voltmeter
2 1/16″ 240-33 ohm fuel level
Includes oil pressure, water temperature, fuel level, and either GPS Antenna or GM style electronic speedometer senders

Stock bezel must be cut. Stock bezel not included.
Installation Instructions

Gauge Panel Finish

Gauge Series

Speedometer Options

Clear

Description

Gauge Features

Modern LED through-the-dial lighting provides clear visibility during nighttime use
Kit includes fuel level sender (240E/33F), oil pressure sender, water temperature sender, sending unit adapters (1/4″, 3/8”, and 1/2″ NPT adapters), mounting hardware, and detailed instructions for installation.
AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
12 and 16 volt compatible, compatible with nearly every street car or race car electrical system

GPS Speedometer Feature Points

These highly accurate GPS Speedometers include an omnidirectional 10 Hz antenna (10 samples per second) with a 16ft. cable, which is required for operation. The dimensions for the antenna are quite small (1.472 in. x 1.339 in. x 0.508 in.) allowing it to be easily hidden. The GPS antenna utilizes up to 3 GPS satellites simultaneously and samples 10 times per second

Electronic Speedometer Feature Points

Speedometer has a simple 2 mile drive calibration. No dip switches and can be reprogramed at any time to accommodate changes in gear ratio or wheel and tire combination.
Speedometer is compatible with most two wire sine wave and three wire hall effect vehicle speed sensors.

Ships With

Fuel Sender 3262 – Oil Sender 2242 – Water Sender 2258 – GPS Antenna 5283 or 5293
1/8″ NPT Male to 1/8″ compression fitting, 1/8″ NPT Female to 1/8″ compression fitting, 1/8″ NPT to 1/4″ NPT bushing, 3/8″ NPT and 1/2″ NPT adapter fittings.
Brackets Included

Weight	7.5 lbs
Dimensions	17.75 × 9 × 5.25 in
Gauge Panel Finish	Brushed Finish, Polished Finish
Gauge Series	Antique Ivory, Black Diamond, Prestige Pearl
Speedometer Options	140 MPH GPS, 120 MPH Electronic (Wheel Odometer), 120 MPH Electronic (LCD Odometer)
