1965-1966 Ford Mustang Adapter Panels w/ Auto Meter American Muscle Gauges
$896.50
Includes aluminum gauge panel, Auto Meter American Muscle gauges, & LED lights (turn signal & high beam indicators).
Gauges include:
- 3 3/8” speedometer (choose from drop down menu)
- 2 1/16” 100 psi electric oil pressure
- 2 1/16” 100-250 degree electric water temperature
- 2 1/16” 8-18 VDC voltmeter
- 2 1/16” fuel level (choose ohms from drop down menu)
- Sending units are included for oil pressure & water temperature
Mounts into stock or aftermarket bezel. Bezel sold separately.
Description
Gauge Features- Modern white LED through-the-dial lighting provides clear visibility during nighttime use
- Package includes oil pressure sender, water temperature sender, mounting hardware, and detailed instructions for installation.
- AutoMeter’s race proven air-core electric instruments provide quick and accurate readings while keeping hazardous fluids outside of the vehicle
- 12 and 16 volt compatible, compatible with nearly every street car or race car electrical system
- Speedometer has a simple push button, 2 mile drive calibration. No dip switches and can be reprogramed at any time to accommodate changes in gear ratio or wheel and tire combination.
- Speedometer is compatible with most two wire sine wave and three wire hall effect vehicle speed sensors.
- Speedometer features lit LCD odometer – capable of registering one-million miles with two resettable trip odometers
- Oil Sender 2242 – Water Sender 2258
- 3/8″ NPT and 1/2″ NPT adapter fittings
- Brackets Included
Additional information
| Weight | 4.75 lbs |
|---|---|
| Dimensions | 18.25 × 7.5 × 0.75 in |
| Speedometer Options | 160 MPH electric speedometer, 260 KPH electric speedometer |
| Fuel Gauge Options | 75-10 ohms (works w/ stock sender), 240-33 ohms (works w/ ATM3262), 0-90 ohms (late model GM) |
